It’s time for some calculations.
In this post, we are going to explain “How to Calculate Concrete Volume and its ingredients?”
How to Calculate Concrete Volume?
If it is a volume, then we know there must be 3 dimensions, Length, Height, Width or Breadth.
We covered some Basic Surface Area and Volume Formulas.
For Slab, If we need to calculate the concrete volume,
Volume = Length X Breadth X Width/Thickness = 5 X 3 X 0.125 = 3.75 m3
For Beam, If we need to calculate the concrete volume,
Volume = Length X Breadth X Width = 5 X 0.6 X 0.3 = 3.75 m3
For Column, If we need to calculate a concrete volume for the below Columns,
Rectangular Column, Volume = Height X Breadth X Width = 5 X 0.6 X 0.3 = 0.9 m3
Circular Column, Volume = πr2 h= 3.141256 X (0.15)2 X 5 = 0.35 m3
Concrete Ingredients Calculation
For Cement, Sand and Coarse Aggregate.
This is a Volumetric Calculation.
Assuming we need 2 m3 of concrete for M20 Concrete Mix, (Mix Ratio, M20 = 1 : 1.5 : 3)
Total Part of the Concrete = 1+1.5+3 = 5.5 Parts
Therefore, Cement Quantity = (Cement Part / Concrete Parts ) * Concrete Volume
= (1/5.5)* Concrete Volume = (1/5.5)*2 = 0.3636 m3
Density of Cement = 1440 kg/ m3 = 0.3636 X 1440 = 523 kg = 10.5 Approx. Bags
Sand Quantity = ( Sand Part / Concrete Parts ) * Concrete Volume = (1.5/5.5) * 2 = 0.5454 m3
Coarse Aggregate = (Coarse Aggregate Part / Concrete Parts ) * Concrete Volume
= (3/5.5) * 2 = 1.09 m3
Water Cement Ratio
According to IS 10262 (2009), Assuming Water-Cement Ratio for the Concrete as 0.45
Required Amount of Water = W/C Ratio X Cement Volume
Therefore, Water = 0.45 X 0.3636 m3 = 0.16362 m3
Unit Weight of Water = 1000 litres/m3
Required Amount of Water = 0.16362 X 1000 = 163.62 litres
Therefore, we need 10.5 bags of cement, 0.5454 m3 of sand, 1.09 m3 of Coarse aggregates and 163.62 litres of water.
Concrete Ingredients Calculator
Hope you enjoyed the content.
