14 Types of Brick Bonds – Easy to Remember

Are you confused about different types of brick bonds and hard to identify? Not anymore.

The reason for the confusion is, we all assume that every brick bonds are distinguished from others.

But the reality is, there are only 3 basic bonds.

  • English Bond
  • Flemish Bond
  • Special Brick Bonds

The others are the extension of the same bonds according to the need.

Identifying the brick bonds based on our need is the essential step for estimating the accurate (not actually) quantity. We can learn this in upcoming posts.

Let’s get started,

Brick Bond Basics

Brick bonds are actually identified by their faces.

Let’s familiar with that faces.

Six type of Brick Positions

Are you able distinguish this? Then move on

Types of Brick Bonds

To identify any type of brick bonds examine the first three bricks used in the alternative courses.

Stretcher Bond

If you see only stretcher face in all the courses then it is stretcher bond (as easy as that). Half bricks can be used in every alternative course like shown in below

Stretcher-Bond

Header Bond

If you see only headers facing towards you then it is header bond

Header Bond

English Brick Bond

English bond is a stronger bond.

If you see the first three bricks on the alternative courses as,

  • First Course – Course of Stretchers
  • Second Course – Course of Headers  with Quoin Closure (refer the image), it is known as English brick bond

Quoin closure normally placed very near to the sides of doors or piers.

Mind Tip To identify the English and their extension bonds, look at the second course, If you see Header, Closure & Header (HCH) model then it is English Brick Bond.

English-Brick-Bond-Model-1

English Garden Wall Bond

As we said earlier, you can identify the English bond extension by examining the first three bricks on the second course as HCH (Header, Closure & Header).

If the stretchers are used in consequent courses for a number of times (3,5,7) and then followed by header course then it is English Garden Wall Bond.

English-Garden-Wall-Bond

If it is used 5 times consequently then it is known as Scottish Bond.

Scottish-Brick-Bond

If it is used 7 times consequently then it is known as American Bond.

American-Brick-Bond

But in general, all these are referred as English Garden Wall Bond.

Mind Tip: 3,5,7 of consequent stretcher rows followed by header rows are known as English Garden Wall Bond.

The reason – We all know that all the bricks are not manufactured exactly the same. Some looks bumped, if we placed lots of headers in the course it will look bumped on the rear. To give a smooth rear appearance this type of brick bonds will be used.

English Cross Bond

We know by the name English, it has Header, Closure & Header (Mind Tip). If you see the Cross as shown in the picture. Then it is English Cross Bond.

Unlike the English Bond, every alternative course in the stretcher we have one header as shown in the picture. You can identify this bond by the plus sign (highlighted in Blue)

English-Cross-Bond-1



The Difference between English and Flemish Bond

Many people confused to distinguish these two bonds.

For Quick identification,

If you see HCH (Header, Closure & Header) model in alternative courses then it is English Bond

If you see HCS (Header, Closure & Stretcher) model in alternative courses then it is Flemish Bond

Flemish Brick Bond

Flemish bond is the most attractive bond.

You can identify the bond type by examining the alternative courses or by the first three bricks on the same course.

Flemish Brick Bond has Header, Closure & Stretcher (refer the image), in the same course. The closure will be placed up against the corner of the door or openings.

Flemish-Brick-Bond-1

Mind Tip – To identify the English and their extension bonds, look at the second course, If you see Header, Closure & Stretcher (HCS) model then it is Flemish Brick Bond.

Flemish Garden Wall Bond

Like said before, the Flemish bond has Stretcher, Header & Stretcher Model. It is also known as Sussex Bond.

In Flemish Garden Wall Bond, instead of having 1 stretcher & 1 header, here we have 3 in 1, 3 stretchers and 1 header. It is also called balanced bonding. You can see that by the model (refer the image)

3 Stretcher: 1 Header

Flemish-Garden-Bond

Monk Bond

Like Flemish garden wall bond, it is also the variation of the flemish bond, but unless 3 in 1 ratio, we 2 in 1 ratio.

2 Stretchers and 1 header. That’s it 🙂

Monk Bond

Special types of Brick Bonds

We call it as special bonds because we don’t use this often. We use it only for the aesthetic purpose.

These are non-load-bearings bonds.

Diagonal bond

As the name suggest, it staked diagonally as shown in the picture.

Diagonal Brick Bond

Zig Zag Brick Bond or 45 Degree Herring Bone Bond

Again as by the name, it will be raked in a zig-zag manner as shown in the picture.

Zig Zag Brick Bond

Single Basket Weave bond

As shown in the picture, these brick bonds compromises of two sailors laid side by and capped with shiner.

Be familiar with faces with above to understand the bonds.

Single-Basket-Weave-brick-bond

Double Basket Weave bond

As shown in the picture, these brick bonds compromises of two sailors laid side by side topped by two shiners.

Double-Basket-Weave-brick-bond

We hope now you are able to distinguish the bonds much quickly.

Don’t lose heart if you can’t identify them by the first attempt. It will be easy when you use it more.

Happy Learning 🙂 together.
